THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 4
Jun 1/03
3E10
31-50-00
CHART 1 (Sheet 3 of 3)
TROUBLESHOOTING ANNUNCIATOR
Trouble Cause Remedy
AIR/COND DOOR OPEN light Sensor terminals bridged. Remove material between
fails to extinguish. terminals.
Sensor activates at too high
a setting. Replace sensor.
Defective sensor. Replace sensor.
STARTER ENGAGE light Bulb burned out. Replace bulb.
fails to operate.
5A fuse open. Replace fuse.
Sensor activates at too low
a setting. Replace sensor.
Defective sensor. Replace sensor.
STARTER ENGAGE light Starter contactor terminal Replace contactor.
fails to extinguish. shorted.
Defective annunciator. Replace annunciator.
PITOT HEAT OFF/INOP light Bulb burned out. Replace bulb.
fails to operate.
No current to sensor. Check all wire segments
and connections.
Defective sensor. Replace sensor.
PITOT HEAT OFF/INOP light Heat switch fails to open. Replace switch.
fails to extinguish.
Sensor activates at too high
a setting. Replace sensor.
Defective sensor. Replace sensor.
