THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 4
Jun 1/03
3J22
37-00-00
TO VACUUM PUMP NO. 1
(UPPER)
TO VACUUM PUMP NO. 2
(LOWER)
REGULATOR NO. 1
REGULATOR NO. 2
SWITCH NO. 1
SWITCH NO. 2
MANIFOLD
GAUGE
FILTER
INSTRUMENT PANEL
PILOT'S SIDE
(REF)
VIEW LOOKING AFT
(AIRCRAFT STRUCTURE REMOVED, STANDARD INSTALLATION SHOWN)
Vacuum System Installation
Figure 1 (Sheet 1 of 2)
