THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 5
Jun 1/03
3J23
37-00-00
VIEW LOOKING DOWN
(
STANDARD INSTALLATION SHOWN
)
FILTER
GAUGE
VENT
VAC
INSTRUMENT PANEL
(REF)
FWD BULKHEAD (REF)
BL
0.00
FIREWALL
(REF)
TO
VACUUM
PUMP
NO. 2
(LOWER)
TO
VACUUM
PUMP
NO. 1
(UPPER)
MANIFOLD
SWITCH NO. 1
SWITCH NO. 2
REGULATOR NO. 1
REGULATOR NO. 2
Vacuum System Installation
Figure 1 (Sheet 2 of 2)
