Piper 6XT - Page 891

THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 3
Jun 1/03
4H15
61-10-00
CHART 1
PROPELLER TORQUE LIMITS
Description Required Torque (Dry)
Propeller Mounting Nuts 60-70 foot-pounds
Fwd. Bulkhead Attachment Bolts 20-24 inch-pounds
Spinner Attachment Screws 20-22 inch-pounds
Propeller Installation
Figure 2 (Sheet 1 of 2)
