Pivot SHUTTLE User Manual

www.pivotcycles.com 1.877.857.4868
Small Parts Table
NUMBER PART NAME DESCRIPTION TORQUE *
8 FP-CVR-EBIKE-BATT Battery Cover
9 FP-CVR-EBIKE-SKD-PLT Skid Plate
10 FP-MNT-FRNT-BATT-V1 Front Battery Mount
11 FP-SCW-BTN-M2.5*12-SLFTAP M2.5x12 Self-tapping Torx Screws
12 FP-GKT-BATT-CVR-DS-V1 E-Bike Carbon DS Battery Cover Gasket
13 FP-GKT-BATT-CVR-NDS-V1 E-Bike Carbon NDS Battery Cover Gasket
14 FP-GKT-BATT-CVR-BLT-V1 E-Bike Carbon Rear Bolt Battery Cover Gasket
15 FP-RDH-TA-12MM-BLK-V2 Direct Mount Rear Derailleur Hanger 12mm TA
16 FP-SCW-SCK-M5*10
M5x10 Rear Derailleur Hanger Socket Screw 7 Nm (5 lb·ft)
M5x10 Battery Bracket Socket Screw 7 Nm (5 lb·ft)
17 FP-WSH-5I*10O*1W M5 Battery Mount Washers
18 FP-BLT-M8*38-BLK M8x38 Front Shock Bolt 13 Nm (10 lb·)
19 FP-BRG-6902-LLUMAXECN 28mm 6902 Ext'd Max-E Bearing
20 FP-LNK-LL-50MM-V1 50mm Out-to-Out Lower Link
21 FP-LNK-UL-70MM-DSM-V1 70mm Direct Shock Mount Upper Link
22 FP-PIN-SHK-M8*15O-BLK 15x58mm M8 Rear Shock Pin 13 Nm (10 lb·)
23 FP-BLT-M8*12-BLK M8x12 Rear Shock Bolt 13 Nm (10 lb·)
24 FP-WSH-SPC-M15*13 M15x13 Rear Shock Spacer
25 FP-BLT-M14*17-BLK M14x17 Upper Link Bolt 35 Nm (27 lb·)
26 FP-BLT-M14*20-BLK-V2 M14x20 Lower Link Bolt 35 Nm (27 lb·)
27 FP-CLM-MECH-FRM-V1 Internal Routing Cable Clamp
28 FP-CLM-DI2-SLV-BLK-V1 Di2 Wire Sleeve for Cable Clamps
29 FP-CLM-DUAL-FRM-V1 Internal Routing Dual Clamp
30 FP-SCW-FLT-M3*10 M3x10 Cable Clamp Screw (Included w/ Clamp)
31 FP-GDE-DI2-7*8*2.5*2.5 7x8mm Di2 Wire Guide
32 FP-GDE-DUAL-7*13*5-V1 Extended Dual Wire/Housing Guide
33 FP-MNT-CG-V1 Chain Guide Mounting Plate
34 FP-SCW-FLT-M5*12 M5x12 CG Mounting Screw
35 FP-GKT-BATT-IND-V1 Battery Indicator Gasket
36 FP-GKT-BATT-CHG-V1 Battery Charging Port Gasket
37 FP-BLT-M6*8-BLK-V1 M6x8 Battery Cover Bolts 5 Nm (4 lb·)
38 FP-SCW-SCK-M8*18-R1 M8x18 Motor Mounting Screw 13 Nm (10 lb·)
39 FP-SCW-SCK-M8*30-R1 M8x30 Motor Mounting Screw 13 Nm (10 lb·)
40 FP-WSH-8I*12O*1W M8 Motor Mount Bolt Washer
41 EBIKE CS GUARD E-Bike Carbon Chainstay Protector
42 EBIKE SS GUARD E-Bike Carbon Seatstay Protector
43 EBIKE SP GUARD E-Bike Carbon Skid Plate Protector
44 EBIKE BC GUARD E-Bike Carbon Battery Cover Protector
45 EBIKE SS EXT GUARD E-Bike Extended Seatstay Protector
99 157MM THROUGH AXLE V3 157mm Thru Axle w/ Washer
*
= grease = anti-seize = anti-seize or grease = loctite 243 (applied to female threads)
SCHEMATICS
14

Pivot SHUTTLE Specifications

General

Suspension	Full Suspension
Brake Type	Hydraulic Disc
Category	E-Bike
Wheel Size	29"
Gears	Shimano XT
Weight	Approx. 22.5 kg
