www.pivotcycles.com 1.877.857.4868
Setting Rebound Damping on the Fox DPX2
• Rebound is set from the most open (fully counter-clockwise) position.
• The rebound setting is determined by the air pressure in the shock.
• Refer to the table below for the suggested rebound setting. The number in the chart
refers to how many clicks in (clockwise) from the open setting the rebound should be set.
AIR PRESSURE
SUGGESTED REBOUND
SETTING
[bar] [psi]
< 8.3 <120 Open
8.3 - 9.7 120-140 1
9.7 - 11 140-160 2
11 - 12.4 160-180 3
12.4 - 13.8 180-200 4
13.8 - 15.2 200-220 6
15.2 - 16.5 220-240 7
16.5 - 17.9 240-260 9
17.9 - 19.3 260-280 11
19.3 - 20.7 280-300 12
BIKE SET-UP
Setting Air Pressure on the Fox 36 Fork
• Fox recommends setting sag between 15% and 20% of the total fork travel. The Shuttle comes with a
150mm fork, so the proper sag measurement is 22.5 - 30.0mm.
• The air pressure in the Fox 36 fork should not exceed 8.3 [bar] (120 [psi]).
• To achieve the proper sag, reference the chart below for an initail starting point.
RIDER WEIGHT
FOX 36
AIR PRESSURE
[kg] [lbs]
55 - 59 120 - 130 3.0 [bar] / 43 [psi]
59 - 64 130 - 140 3.2 [bar] / 46 [psi]
64 - 68 140 - 150 3.5 [bar] / 51 [psi]
68 - 73 150 - 160 3.8 [bar] / 55 [psi]
73 - 77 160 - 170 4.1 [bar] / 59 [psi]
77 - 82 170 - 180 4.3 [bar] / 63 [psi]
82 - 86 180 - 190 4.6 [bar] / 67 [psi]
86 - 91 190 - 200 4.9 [bar] / 71 [psi]
91 - 95 200 - 210 5.2 [bar] / 75 [psi]
95 - 100 210 - 220 5.4 [bar] / 79 [psi]
100 - 105 220 - 230 5.7 [bar] / 83 [psi]
105 - 109 230 - 240 6.0 [bar] / 87 [psi]
109 - 114 240 - 250 6.3 [bar] / 91 [psi]
