User manual - ATR142- 33
mast.
Description
w.pro.
Write Process
Write process value
r.w.co.
Read/Write
Command Setpoint
Write and read command setpoint
value
w.ou.p.
Write Output
Percentage
Write output percentage rated by P.I.D.
function (Range 0-10000)
r.w.a.1
Read/Write Alarm 1
Write and read alarm 1 setpoint value
The read/written value might be rescaled according to the
proportion described in the following table:
mast.
Value limits input Limits of rescaled value
Min Max Min Max
w.pro.
Write
Process
Lo .L.i .
Lower
Limit
Input
u p. L.i .
Upper
Limit
Input
Lo . L. r.
Lower
Limit Re-
transmis-
sion
u p . L. r.
Upper
Limit Re-
transmis-
sion
r.w.co.
Read/Write
Command
Setpoint
Lo .L. s .
Lower
Limit
Setpoint
u p. L. s .
Upper
Limit
Setpoint
Lo . L. r.
Lower
Limit Re-
transmis-
sion
u p . L. r.
Upper
Limit Re-
transmis-
sion
w.ou.p.
Write
Output
Percentage
0 10000
Lo . L. r.
Lower
Limit Re-
transmis-
sion
u p . L. r.
Upper
Limit Re-
transmis-
sion
r.w.a.1
Read/Write
Alarm 1
Lo .L. s .
Lower
Limit
Setpoint
u p. L. s .
Upper
Limit
Setpoint
Lo . L. r.
Lower
Limit Re-
transmis-
sion
u p . L. r.
Upper
Limit Re-
transmis-
sion
