User manual - ATR142- 7
3 Technical Data
3.1 General Features
Display 4 0.40 inch displays + 4 0.30 displays
Operating
temperature
1 relays 8A + 1 Ssr + RS485
Sealing
IP65 front panel (with gasket)
IP30 box, IP20 terminals
Material Polycarbonate UL94V2 self-extinguishing
Weight 100 g
3.2 Hardware Features
Analogue
input
AN1. Configurable
via software.
Thermocouple type:
K, S, R, J. Automatic
compensation of cold
junction from 0°C to
50°C.
Thermoresistance:
PT100, PT500, PT1000,
Ni100, PTC1K, NTC10K
(β 3435K). Linear:
0-10V, 0-20 or 4-20mA,
0-40mV
Potentiometers:
6KΩ, 150KΩ,
Tolerance (25°C)
+/-0.2 % ± 1 digit (full
scale) for thermocouple
input, thermo-
resistance and V/mA.
Cold junction accuracy
0.1°C/°C
Impedance:
0-10V: Ri>110K Ω
0-20mA: Ri<5Ω
4-20mA: Ri<5Ω
0-40mV: Ri>1MΩ
Relay
output
2 relays (ATR142-ABC)
1 relay (ATR142-ABC-T)
Configurable as
command and/or alarm
output
Contacts:
Q1: 8A-250V~
for resistive loads
Q2: 5A-250V~
for resistive loads
SSR
output
1 SSR Configurable as
command output and/
or alarm output.
12Vdc/30mA
