6 - ATR142 - User manual
Introduction
Thank you for choosing a Pixsys controller.
With the ATR142 model Pixsys makes available in a single
device multiple options related to sensor input and actuators
command in addition to the extended power range 24…230
Vac/Vdc. With 17 sensors to select and outputs configurable
as relay or SSR command, the user or retailer can reduce
stock by rationalising investment and device availability. The
series includes a version equipped with serial communication
RS485 Modbus. The configuration is further simplified by the
Memory cards which are provided with internal battery and
therefore do not require cabling to power the controller.
1 Safety standards
Carefully read the instructions and safety measures in this
manual before using the device. Disconnect power before
performing any interventions on the electrical connections
or hardware settings. Only qualified personnel may use/
perform maintenance in full respect of the technical data and
declared environmental conditions.
Do not dispose of electrical appliances together with
household waste. In compliance with the European Directive
2002/96/EC, waste electrical equipment must be collected
separately for eco-compatible reuse or recycling.
2 Model Identification
Refer to the table below to easily select preferred model.
All versions available with power 24…230 Vac/Vdc +/-15%
50/60Hz – 4,6VA
ATR142-ABC 2 relays (8A+5A) + 1 SSR
ATR142-ABC-T 1 relays 8A + 1 Ssr + RS485
