User manual - ATR142- 25
Press Effect Do
1 FNC
Press until
ti m .1
or
ti m . 
2
visualized on display 1.
2
“
n
”
Start the Timer. Display
2 shows decrementing
time and Led
R
switches on (fixed for
timer 1, flashing for
timer 2).
Back to point 1, after
selection of running
Timer
press “
n
” to stop
counting. Led
R
switches off.
At elapsing of Timer the led
R
switches off and display
2 flashes, showing the programmed time until any key is
pressed. Start/Stop of Timer by digital input is NOT available
for dual timer mode.
9.3 Dual sequential timer
This option enables two Timers and the time is selectable by
the operator. At elapsing of Timer 1, counting of Timer 2 will
automatically start . At elapsing of Timer 2, counting will stop.
To achieve operation of dual sequential Timer set the
parameter 63
t m r. f .
as follows:
•
d.s.t.s.
(Double Sequential Timer Seconds) time-basis in
seconds (mm.ss)
•
d.s.t.m.
(Double Sequential Timer Minutes) time-basis in
minutes (hh.mm)
To start/stop the Timer, press key FNC for 1s. During the
counting, Led
R
is On (fixed for Timer 1, flashing for Timer 2)
and display2 shows decrementing time. Start is always made
on Timer 1. At elapsing of Timer, led
R
is switched off and
display 2 shows setpoint value. Start/Stop of Timer is possibile
also by digital input, selecting
t.1.s.s.
on parameter 50
d Gt.i .
