For the calibration procedure refer to the following table:
Press E ff e c t Do
1 FNC
Exit parameters
confi guration. Display 2
shows the writing
La t c.
Place the sensor on the
minimum operating
position (associated
with
Lo .L.i .
)
2
“
m
”
Set the value to
minimum.
The display shows
Lo w
Place the sensor on the
maximum operating
position
(associated with
u p. L.i .
)
3
“
n
”
Set the value to
maximum.
The display shows
Hi G t
To exit standard
procedure press FNC.
For “virtual zero”
settings place the
sensor on zero point.
4
SET
Set the virtual zero
value. The display shows
ui rt .
NB: for selection
of
u.0in.
the procedure
on point 4 should
be followed at each
re-activation.
To exit the procedure
press FNC.
Max
Min Zero
8.11 Digital input functions
On ATR142 model, digital input can be enabled by using
parameters 48
op.mo.
and 50
d Gt.i .
• Parameter 48
op.mo.
 co n t.
: Operating as controller.
NB: When using this settings, parameter 50
d Gt.i .
is
ignored.
