56 - ATR142 - User manual
Table of configuration parameters
1
c.out
Command Output 35
2
SEN.
Sensor 36
3
d. p.
Decimal Point 37
4
Lo .L. s .
Lower Limit Setpoint 37
5
U P. L.S.
Upper Limit Setpoint 37
6
Lo .L.i .
Lower Linear Input 37
7
u p.L.i .
Upper Linear Input 37
8
La t c.
Latch On Function 37
9
o . c a L.
Offset Calibration 38
10
G. ca L.
Gain Calibration 38
11
act. t.
Action type 38
12
c.re.
Command Reset 38
13
c.s . e.
Command State Error 38
14
c.Ld.
Command Led 38
15
c.HY.
Command Hysteresis 39
16
c.d e.
Command Delay 39
17
c.s . p.
Command Setpoint Protection 39
18
p. b.
Proportional Band 39
19
t.i .
Integral Time 39
20
t.d.
Derivative Time 39
21
t. c.
Cycle Time 40
22
o.po.L.
Output Power Limit 40
23
aL.1
Alarm 40
24
a .1 . s . o .
Alarm 1 State Output 41
25
a .1 . r e .
Alarm 1 Reset 41
26
a .1 . s . e .
Alarm 1 State Error 41
27
a.1.Ld.
Alarm 1 Led 41
28
a .1 . H Y .
Alarm 1 Hysteresis 41
29
a .1 . d e .
Alarm 1 Delay 42
30
a .1 . s . p .
Alarm 1 Setpoint Protection 42
31
aL.2
Alarm 2 42
32
a .2.s . o .
Alarm 2 State Output 43
