Pixsys ATR144 - GROUP G - d. 1. 2 - Digital input 2

User manual - ATR144- 65
with D.I. activated
t.2. s. E. Timer 2 Start End. D.I. starts and
stops the timer 2(impulsive)
t.2.S t a. Timer 2 Start. D.I. starts the timer 2(impulsive)
t.2.E n d Timer 2 End. D.I. stops the timer 2(impulsive)
Lo.cfG. Lock configuration and setpoints.
u p. k e y Simulates the functioning of UP key.
d o w n.k. Simulates the functioning of DOWN key.
fn c. k. Simulates the functioning of FNC key.
s et. k. Simulates the functioning of SET
key (password entry excluded).
95 d.i .1. c. Digital Input 1 Contact
Defines the resting contact of the digital input 1.
n.o pen Normally open (Default)
n.cLos. Normally closed
96÷100 Reserved Parameters - Group F
Reserved parameters - Group F.
