22 - ATR227 - User manual
43 o.cL.t. Output Control Type (Password 5678)
Select output control type in case of PID regulation
tiME
Time control Default
bSt.F.
Burst re control
A.bt.F.
Advanced Burst re control
PHs.A.
Phase angle control
F.PH.A.
Fixed Phase angle control
44 PHS. d . Phase Displacement (Password 5678)
Select the phase displacement in case of inductive load when using the phase
angle control
-90..90 degrees.> Default 0°.
45 F.P.A.P. Fixed Phase Angle Percentage (Password 5678)
Select the output % when “Fixed Phase Angle” control is selected.
10.0..90.0% .> Default 80.0%
46 L.L.P.P. Lower Limit Phase Angle Percentage (Password 5678)
Select the min. value for the command output % with Phase Angle control.
0..40%, Default: 10%.
47 u .L.P.P. Upper Limit Phase Angle Percentage (Password 5678)
Select the max. value for the command output % with Phase Angle control
60..100%, Default: 90%.
48 p. b. Proportional Band (Password 5678)
Process intertia in °C/°F
0 ON / OFF if t.i. is equal to 0 (Default)
1-9999 °C/°F
49 i.t. Integral Time (Password 5678)
Process inertia in seconds.
0.0-999.9 seconds (0 = integral disabled), Default 0.0
50 d.t. Derivative Time (Password 5678)
Normally ¼ of integral time.
0.0-999.9 seconds (0 = derivative disabled), Default 0.0
51 d.b. Dead Band (Password 5678)
0-1000 [digit1] (degrees.tenths for temperature sensors) (Default: 0)
