ep46L-B - Rear
12 ep46L/ep55L User Manual
ep46L-B - Rear
The dimensions are in millimeters unless otherwise noted.
Standard Inputs
Optional HD-SDI Inputs
8X M8 THREADED INSERT
15.7”
400mm
15.7”
400mm
7.9”
200mm
Optional
HD-SDI
LAN
DisplayPort HDMI 1 HDMI 2
VGADVI-D
Touch USB
PC
Audio
In
IR
Extender
Line
Out
COMPONENTRS232C Audio InS-Video Video Audio In
SDI OUTSDI INSDI IN
