ep46L/ep55L User Manual 27
8 Side by Side: Press the P-POSITION button and then “Side by side” mode. The
main source and the subsource will be on the screen display.
PIP Screen Table
The following table shows sources that can be displayed in a PIP window when
sources in the main window are displayed.
MAIN PIP
PIP
VGA HDMI 1 HDMI 2 DVI
Display
Port
Video
(Composite)
S-Video Component HD-SDI 1 HD-SDI 2
M
a
i
n
VGA Yes Yes Yes Yes Yes Yes Yes Yes Yes
HDMI 1 Yes Yes Yes Yes Yes Yes Yes
HDMI 2 Yes Yes Yes Yes Yes Yes Yes
DVI Yes Yes Yes Yes Yes Yes Yes
DisplayPort Yes Yes Yes Yes Yes Yes Yes Yes Yes
Video Yes Yes Yes Yes Yes Yes Yes Yes
S-Video Yes Yes Yes Yes Yes Yes Yes Yes
Component Yes Yes Yes Yes Yes Yes Yes Yes Yes
HD-SDI 1 Yes Yes Yes Yes Yes Yes Yes Yes
HD-SDI 2 Yes Yes Yes Yes Yes Yes Yes Yes
