Graphics Mode
30 ep46L/ep55L User Manual
MainMenu Submenu
Secondary
Menu
Description Setting
Image Position 0~‐100
0~100
▲accordingtoresolution
▼accordingtoresolution
Phase 0~63 According to resolution
Clocks 0~100 According to resolution
Flesh Tone Disabled in Graphics mode
IRFM Select the anti burn-in mode
function
Off, On
Baud rate Setting the baud rate of the display 115200, 38400, 19200, 9600
Smart light control Select the Backlight control function
DCR (Dynamic contrast) – from the
input source
Light Sensor – from ambient light
Off, DCR, Light Sensor
Ethernet
Setup
Enable
Network
Enable the network feature Yes, No
Dynamic IP Enable the Dynamic IP mode Disable, Enable
Static IP
Address
Set the static IP address 255.255.255.255 (0.0.0.0)
Subnet Mask Set the subnet mask 255.255.255.255 (0.0.0.0)
Gateway Set the gateway address 255.255.255.255 (0.0.0.0)
DNS Address Set the DNS address 255.255.255.255 (0.0.0.0)
Save Network
Settings
Update the IP settings to the net
device
Yes, No
Load Default
Settings
Load the default network settings Yes, No
Device MAC Show the unique address assigned to
network interfaces
Factory Reset Reset to the factory default setting Yes, No
System
Status
Channel
Information
Source Show the name of the input source
Resolution Show the current resolution
Firmware
Version
Show the firmware of the LCD
