User’s Manual of IVS-H125 Series
10
1.4. Product Specification
Model
IVS-H125 IVS-H125P
Video Compression H.264 / MPEG-4 / M-JPEG
Video Resolution 4CIF(D1), CIF, QCIF
Frame Rate 30/25 (NTSC/PAL) fps in all resolutions
Image Setting
AE, AWB
3D Noise reduction
Color, brightness, sharpness, contrast
Mirror / Flip
8 Privacy Masks
Text, time and date overlay
Streaming
Simultaneously multi-profile streaming
Streaming over UDP, TCP, or HTTP HTTPS
M-JPEG streaming over HTTP (server push)
Supports 3GPP mobile surveillance (MPEG4)
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4/H.264)
ROI
Audio
Audio Streaming Two-way Audio
Audio Compression
RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR
Microphone External microphone input
Audio Output
Adjustable audio output gain
Network and Configuration
Standard
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
Protocol
IPv4, IPv6, TCP/IP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS,
DDNS, DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP,
PPPoE, 3GPP, ICMP, Samba
Security
Password protection, IP address filtering, HTTPS encrypted data
transmission, user access log
Users
20 clients on-line monitoring at the same time
System Integration
Application
Programming Interface
Open API for software integration
ONVIF Compliant
Alarm Triggers
Intelligent video motion detection, audio detection and external input
Alarm Events
File upload via FTP, Samba to NAS, micro SD card or email
Notification via email, HTTP, and TCP
External output activation
Audio alerting output
Pre- and post-alarm buffering
Environment Specifications
