User’s Manual of IVS-H125 Series
35
Chapter 6.
Configuration & Operation
6.1. Network Configuration
6.1.1 Network
This section provides the menu of connecting the device through Ethernet cable.
MAC address Display the Ethernet MAC address of the device. Note that user cannot
change it.
Obtain an IP
address
automatically
(DHCP)
Enable this checked box when a DHCP server is installed on the
network to issue IP address assignment. With this setting, the IP
address is assigned automatically. If this device cannot get an IP
address within limited tries, the device will assign a default IP address
for 192.168.0.20.
If you do not select “Obtain an IP address automatically”, then you
need to enter these network parameters by yourself.
IP Address This address is a unique numbers that identifies a computer or device
on the WAN or LAN. These numbers are usually shown in groups
To Next Page
