User’s Manual of IVS-H125 Series
61
versus video quality under the limited bandwidth.
GOP Control: Defines the Intra/Inter-frame (I/P) ratio of this profile. For
example, set the GOP to 30, then the video stream will have
one Intra-frame every 30 frames.
Multicast:
Enable or disable the multicast function.
Multicast Video:
IP address and port for multicast video streaming of the
selected profile.
Time to live
Time to live (TTL) is a mechanism that limits the lifespan of
data in a computer or network. Once the prescribed event
count or timespan has elapsed, data is discarded. TTL
prevents a data packet from circulating indefinitely.
Always Enable Multicast
Multicast streaming is always enabled or by request.
Warning!!!
To enable the multicast streaming, you shall make sure your Intranet does
support multicast function. Otherwise, your Intranet may occur network storm
seriously.
