Planet VC-234G User Manual

10
 LED Indicators – VC-234G
 System
LED Color Function
PWR Green
Lit
Indicates that the VDSL2 Bridge has
power.
Off
Indicates that the VDSL2 Bridge has no
power.
 VDSL
LED Color Function
VDSL Green
Lit
Indicates that the VDSL link is
established.
Fast
Blink
Indicates that the VDSL link is at training
status (about 10 seconds).
Slow
Blink
Indicates that the VDSL link is at idle
status.
CO Green Lit
Indicates the VDSL2 Bridge is running in
CO mode.
CPE Green Lit
Indicates the VDSL2 Bridge is running in
CPE mode.
 100/1000BASE-T Port
LED Color Function
1000 Green
Lit
Indicates that the port is operating at
1000Mbps.
Blink
Indicates that the VDSL2 Bridge is
actively sending or receiving data over
that port at 1000Mbps.
Off
Indicates that the port is link down or
1000Mbps.
