User’s Manual of WNRT-617
-6-
Chapter 2. Hardware Installation
Please follow the instruction below to build the wireless network connection between WNRT-617 and your
computers.
2.1 Hardware Description
2.1.1 The Front Panel
The front panel provides a simple interface monitoring the router. Figure 2-1 shows the front panel of
WNRT-617.
Front Panel
Figure 2-1 WNRT-617 Front Panel
WPS/Reset Button
ACTIVE TIME
WPS
Press and hold the button less than 5 seconds for WPS configuration
Reset Press and hold the button more than 8 seconds to the factory default setting
