User’s Manual of WNRT-617
-72-
External Port - External port, which the router opened for the
application.
Protocol - Shows which type of protocol is opened.
Internal Port - Internal port, which the router opened for local
host.
IP Address - The UPnP device that is currently accessing the
router.
Status - The port’s status displayed here. “Enabled” means that
port is still active. Otherwise, the port is inactive.
Table 5-26
Click Refresh to update the Current UPnP Settings List.
5.9 Security
There are four submenus under the Security menu as shown in Figure 5-30: Basic Security,
Advanced Security, Local Management and Remote Management. Click any of them, and you will
be able to configure the corresponding function.
Figure 5-30 The Security menu
5.9.1 Basic Security
Choose menu “Security → Basic Security”, you can configure the basic security in the next screen.
