TECHNICAL SPECIFICATIONS
58 Planmeca Intra X-ray Unit
User’s Manual
Target angle with respect to the reference axis
16°
Dimensions of the tube head assembly
(WxHxD) 175mm x 105mm x 165mm
Weight of the tube head assembly
3.1 kg
Values of loading factors concerning leakage radiation
70 kV, 8 mA
Tolerances of the focal spot on the reference axis
X= ±0.5 mm (sideways)
Y= ±0.5 mm (in depth)
Z= ±0.5 mm (in height)

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
