Plus U3-880 - Projector Parts and Controls; Top, Front, and Side Panel Identification

E – 6
PLUS
AUTOSOURCEPOWER
POWER
OPEN
STATUS
Parts and controls
Top, front and side panel view
Speaker [10, 18]
Remote Sensor [5]
Focus ring [15]
Ventilation slots [3]
Lens [3, 9]
Adjuster button [15]
Control panel
POWER indicator [14,16]
POWER button [14,16]
STATUS indicator [32]
AUTO button [18]
SOURCE button [14, 16]
Bottom
For operational instructions, refer to the page indicated in brackets.
Rear adjuster [15]
Lamp cover screw [33]
Front adjuster [15]
Ventilation slots [3]
POWER STATUS
POWER SOURCE AUTO
Sliding lens cap [3, 14]
Lamp cover [33]
Exhaust vents [3]
