E – 7
RGB / YCbCr
S VIDEO
VIDEO
MOUSE
AUDIO
AUTO
SOURCE
POWER
POWER STATUS
Rear and side panel view
This security slot supports the MicroSaver
®
Security
System. MicroSaver
®
is a registered trademark of
Kensington Microware Inc. The logo is trade-
marked and owned by Kensington Microware Inc.
Ventilation slots [3]
Remote sensor [5]
Built-in security slot [see below]
AC IN terminal [14]
Rear adjuster [15]
AUDIO MOUSE RGB
/
YCbCr
VIDEOS-VIDEO
Terminal Panel
MOUSE connector [17]
AUDIO jack [10, 11, 12] VIDEO jack [10]
S-VIDEO jack [10]
Built-in Security Slot
RGB/YCbCr connector [11, 12]
Ventilation slots [3]
