PH(X)-25 TECHNICAL SPECIFICATIONS
ELECTRICAL
Main Voltage: ______________________________________ 3 x 208-230V, 50/60Hz
Electrical Consumption: (2 x 4 kW Heaters) _____________________ 40 A @ 3 x 230V
Electrical Consumption: (2 x 5 kW Heaters) _____________________ 49 A @ 3 x 230V
Electrical Consumption: (2 x 6 kW Heaters) _____________________ 57 A @ 3 x 230V
Main Voltage: _________________________________________ 1 x 208-230V, 60Hz
Electrical Consumption: (2 x 4 kW Heaters) _____________________ 61 A @ 1 x 230V
Electrical Consumption: (2 x 5 kW Heaters) _____________________ 70 A @ 1 x 230V
Electrical Consumption: (2 x 6 kW Heaters) _____________________ 78 A @ 1 x 230V
Material Heater Power: (2 x 4 kW) ______________________________________ 8 kW
Material Heater Power: (2 x 5 kW) _____________________________________ 10kW
Material Heater Power: (2 x 6 kW) _____________________________________ 12kW
Hose Transformer Power: _____________________________________ 3 KVA (90 V)
Electrical Motor Power: ______________________________________________ 3 HP
Frequency: (Single Phase) ___________________________________________ 60 Hz
Frequency: (Three Phase) _________________________________________ 50/60 Hz
CAUTION! Inside the console is a Terminal Strip for
connecting the main power (wire not supplied) to the
PH Series Proportioner. This electrical connection
must be made only by a qualified electrician.
MECHANICAL
Maximum working pressure (with 120 pumps): _________________ 2,000 psi (138 bar)
Maximum working pressure (with 80 pumps): __________________ 3,000 psi (207 bar)
Maximum production ratio 1:1 (with 120 pumps): ____________ 25 lbs/min (12.5 kg/min)
Maximum production ratio 1:1 (with 80 pumps): ________________ 1.4 GPM (5.6 L/min)
Minimum production: ______________________________________ 2 lb/min (1kg/min)
Maximum hose length: _________________________________________ 310 ft (93 m)
Approximate weight (Hydraulic Tank empty): _____________________ 420 lbs (190 kg)
Approximate weight (Hydraulic Tank full @ 20 gal, 76 liters): ________ 594 lbs (269 kg)
Dimensions: _______________________________________ 30in W x 26in D x 45in H
Dimensions (Metric): ____________________________ 76cm W x 66cm D x 114cm H
