PH(X)-40 TECHNICAL SPECIFICATIONS
ELECTRICAL
Main Voltage: ______________________________________ 3 x 208-230V, 50/60Hz
Electrical Consumption: (2 x 7.5 kW Heaters) ___________________ 75 A @ 3 x 230V
Electrical Consumption: (2 x 9.0 kW Heaters) ___________________ 89 A @ 3 x 230V
Electrical Consumption: (2 x 10.5 kW Heaters) _________________ 103 A @ 3 x 230V
Main Voltage: _________________________________________ 1 x 208-230V, 60Hz
Electrical Consumption: (2 x 7.5 kW Heaters) __________________ 130 A @ 1 x 230V
Material Heater Power: (2 x 7.5 kW) ___________________________________ 15 kW
Material Heater Power: (2 x 9.0 kW) ___________________________________ 18 kW
Material Heater Power: (2 x 10.5 kW) __________________________________ 21 kW
Hose Transformer Power: ____________________________________ 5 KVA (120 V)
Electrical Motor Power: ______________________________________________ 5 HP
Frequency: (Single Phase) ___________________________________________ 60 Hz
Frequency: (Three Phase) _________________________________________ 50/60 Hz
CAUTION! Inside the console is a Terminal Strip for
connecting the main power (wire not supplied) to the
PH Series Proportioner. This electrical connection
must be made only by a qualified electrician.
MECHANICAL
Maximum working pressure (with 120 pumps): _________________ 2,000 psi (138 bar)
Maximum working pressure (with 80 pumps): __________________ 3,500 psi (241 bar)
Maximum production ratio 1:1 (with 120 pumps): _____________ 40 lbs/min (20 kg/min)
Maximum production ratio 1:1 (with 80 pumps): ________________ 2.5 GPM (1.0 L/min)
Minimum production: _________________________________________ 2 lb/min (1 kg)
Maximum hose length: _______________________________________ 410 ft (123 m)
Approximate weight (Hydraulic Tank empty): _____________________ 420 lbs (190 kg)
Approximate weight (Hydraulic Tank full @ 20 gal (76 liters) ________ 594 lbs (269 kg)
Dimensions: _______________________________________ 30in W x 26in D x 45in H
Dimensions (Metric) ____________________________ (76cm W x 66cm D x 114cm H)
