PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
63
"R" PUMP ASSEMBLY (PU-05002-120 & PU-05002-80)
ITEM
QTY
PART NUMBER
DESCRIPTION
FOR PUMP
1*
1
PU-05032
"R" PACKING RETAINER FLANGE; SIZE 120
PU-05002-120
1
PU-05032-80
"R" PACKING RETAINER FLANGE; SIZE 80
PU-05002-80
2
4
PU-05026
TIE ROD; 3/8-24
ALL
3
1
PU-01013A
CYLINDER FLANGE GASKET
ALL
4*
1
PU-05014
PUMP FLANGE; SIZE 120
PU-05002-120
1
PU-05014-80
PUMP FLANGE; SIZE 80
PU-05002-80
5*
1
PU-03000
TRIPLE LIP SEAL, 120
PU-05002-120
1
PU-03001
TRIPLE LIP SEAL, 80
PU-05002-80
6*
1
PU-03010
SHAFT BEARING, 120, R
PU-05002-120
1
PU-03011
SHAFT BEARING, 80, R
PU-05002-80
7
2
OR-00046A
O-RING #133; VITON 90D PUMP CYL
ALL
8
1
PU-05017
CROSSOVER TUBE
ALL
9
2
OR-00011A
O-RING; CROSSOVER TUBE #014
ALL
10*
1
PU-05012
CYLINDER; SIZE 120
PU-05002-120
1
PU-05012-80
CYLINDER; SIZE 80
PU-05002-80
11*
1
-
PISTON ASSEMBLY (SEE PAGE 68)
ALL
12
1
-
PUMP BASE ASSEMBLY (SEE PAGE 69)
ALL
13
4
PU-05027
WASHER
ALL
14
4
PU-05028
NUT
ALL
15
1
HI-05038
1/4 NPT X 9/16-18 JIC 90 DEG E
ALL
16
1
TN-04186
GREASE FITTING
ALL
17
1
HI-05016
3/4 MPT x 3/4 FPT SW
ALL
