PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
72
PH(X)-25 HEATER ASSEMBLY
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
PH-1
HEATER ASSEMBLY "A" SIDE; 5 KW
1
PH-3
HEATER ASSEMBLY "A" SIDE; 6 KW
1
PH-11
HEATER ASSEMBLY "A" SIDE; 4 KW
2
1
PH-2
HEATER ASSEMBLY "R" SIDE; 5 KW
1
PH-4
HEATER ASSEMBLY "R" SIDE; 6 KW
1
PH-12
HEATER ASSEMBLY "R" SIDE; 4 KW
NOTE: “A” AND “R” SIDE HEATERS ARE MIRRORED. THE ONLY DIFFERENCE IN
PARTS IS THE OULET FITTING (ITEM 19)
