PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
81
FRAME/TANK ASSEMBLY (FR-1)
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
FR-2
UPRIGHT ASSEMBLY
2
4
TN-05704
4" CASTER
3
1
HI-00014-03A
TANK TOP GASKET
4
1
HI-00047A
HYDRAULIC FILL STRAINER
5
1
HI-00002-A-1
TANK TOP GROMMET
6
1
HI-00001A
SIGHT GAUGE
7
1
HI-05041
CASE DRAIN RETURN TUBE 3/8
8
1
HI-05042
CASE DRAIN RETURN TUBE 1/2
9
1
HI-05048
DRAIN PLUG
10
1
MQ-01008A
LUBE BOTTLE BRACKET
11
2
FLOOR STOCK
#8-32 X 1/2 BHCS
12
4
FLOOR STOCK
3/8-16 X 2-1/4 SHCS
13
8
FLOOR STOCK
1/4-20 X 5/8 BHCS
14
8
FLOOR STOCK
1/4 PLAIN WASHER
15
8
FLOOR STOCK
1/4 LOCK WASHER
16
8
FLOOR STOCK
1/4-20 X 5/8 HEX CAP SCREW
17
16
FLOOR STOCK
5/16 LOCK WASHER
18
16
FLOOR STOCK
5/16-18 X 1/2 HEX CAP SCREW
