EN – Installation and operation guide SIMPLE MOVE 102
EN – Installation and operation guide SIMPLE MOVE 102
EN
EN
Product description
▶ Contents of the SIMPLE MOVE set
d
a
b
c
www.polargos.pl
SIMPLE MOVE 102
PL
'LQRPSIAH?ÑKMLR?ȴSÑGÑM@QȇSEG
f
g
j
i
k
l
m
e
Mark Name Qty
a
Drive x 1
b Toothed bar base rack
33 cm x 20 mm
x 13
c Assembly template x 1
d Remote control
with 2 buttons
x 2
e Installation and operation
guide
x 1
Mark Name Qty
n
Nuts M10, galvanized x 8
o Flat washers 10.5x22x2,
galvanized
x 8
p Double-thread screw
10x15 mm
x 4
r Pin 10x60 S12 x 4
Mark Name Qty
f
Earth cable x 1
g Self-tapping screw x 4
h Cable clamp x 1
i Shield screw x 1
j Round gasket x 1
k Insulated round terminal x 1
l Small fl at washer x 2
m Star washer x 2
84
72
232
48
109
218 214
109
180
25
▶ Scope of application
▶ General view of the installation
Mark Name
A
Zone lighting*
B Orange light*
C Antenna*
D Safety edge*
E Photocells*
Mark Name
F
Closing stop
G Opening stop*
H Drive
I Toothed bar
This product is designed as the drive unit of a cantilever gate:
• with a max. length of 6 m and a max. weight
of 400 kg
• made of PVC, wood, or metal
• in residential properties..
▶ Dimensions
*optional accessories
SIMPLE MOVE 102
for POLARGOS
You will also need:
A
B
C
F
I
D
E
H
G
