Polaris 2009 Ranger RZR 800 EFI User Manual

5.19
BODY / STEERING / SUSPENSION
5
Exploded View (RZR) Exploded View (RZR “S”)
Upper
A-arm
Lower
A-arm
Grease
Screws
Ball Joint
Pinch
Bearing
CV Shield
Bushings
33 ft. lbs.
(45 Nm)
Pivot Tube
Bushing
Grease Zerk
Ball Joint
Carrier
Bolts
Zerk
17 ft. lbs.
(23 Nm)
33 ft. lbs.
(45 Nm)
Pivot Tube
Upper
A-arm
Lower
A-arm
Grease
Screws
Ball Joint
Pinch
Bearing
CV Shield
Bushings
33 ft. lbs.
(45 Nm)
Grease
Ball Joint
Carrier
Bolts
Zerk
17 ft. lbs.
(23 Nm)
33 ft. lbs.
(45 Nm)
Pivot
Zerk
Tube
Pivot
Tube
Bushings
