6.27
CLUTCHING
6
Exploded View
Compression
Thrust
Washer
Cam
(Helix)
T25
Retaining
Ring
Roller
Pin
Slotted
Ball
E-Clips
Spring
Spider
Dampener
Outer
Spider
Spider
Insert
Stationary
Sheave
Bearing
Spring Pin
Moveable
Sheave
Clutch
Shaft
Roller
Retaining
Ring
Screws
