4.27
The fuel injectors are non-serviceable. If diagnosis
indicates a problem with either injector, test the
resistance of the fuel injector (s) by measuring between
the two pin terminals
w
:
Fuel Injector Resistance Specification:
11.4 - 12.6 Ω
NOTICE
Be sure to connect the PTO harness lead to the PTO
injector and the MAG harness lead to the MAG injector
to ensure proper engine operation.
FUEL INJECTOR REPLACEMENT
1. Lift the cargo box assembly.
2. Be sure the engine has cooled enough to work on.
3. Loosen the hose clamps
q
retaining the intake
plenum
w
to the throttle body.
4. Remove the two screws
e
retaining the intake
plenum.
5. Remove the driver’s seat and disconnect the negative
battery cable.
FUEL SYSTEM
