INTERIOR BODY COMPONENT ASSEMBLY VIEW - GENERAL 4
q
Panel, Close-off Rear Upper
g
Console, Center LH
w
Panel, Service
h
Console, Center RH
e
Panel, Close-off Rear Lower
j
Panel, Console Service
r
Panel, Service
k
Console, Center Top
t
Panel, Floor Upper
l
Console, Center Cover
y
Floor, Main LH
1(
Handle, Grab
u
Floor, Main RH
2)
Holder, Cup
i
Plug, Floor Drain
2!
Storage, Underseat
o
Panel, Dash Upper
2@
Panel, Close-off Front
a
Dash, Main
2#
Floor, Rear LH
s
Door, Glovebox
2$
Floor, Rear RH
d
Storage, Dash Center
2%
Console, Center Rear Top
f
Panel, Console Controls
2^
Console, Center Rear
