8.33
4. Remove low friction seal pack from bearing
assembly.
5. Remove U-Cup seal from bearing assembly. Note the
direction seal was installed for assembly.
6. Remove external O-ring from bearing assembly.
NOTICE
If internal bearing is damaged, replace with complete
bearing assembly.
SHOCK ASSEMBLY (FOX)
1. Install one retaining ring in the eyelet.
2. Press bearing into the eyelet using Bearing Press or
proper sized socket.
3. Install second retaining ring.
STEERING / SUSPENSION
