10.52
9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
7. Install the fasteners holding the rear fender flair to the
rear fender.
8. Close the cargo box and secure in position.
9. Install the fasteners holding the front fender to the
vehicle. Torque the fasteners to specification.
TORQUE
Front Fender Fasteners:
3.5 lb-ft (4.7 Nm)
10.Install the fastener holding the front fender flair to the
front fender. Torque the fastener to specification.
TORQUE
Front Fender Flair Fastener:
3.5 lb-ft (4.7 Nm)
11. Install the hood onto the vehicle. Refer to “Hood
Installation”page 10.56 procedure.
BODY / FRAME
