40. Install the transmission drain plug and torque to
specification.
TORQUE
Transmission Fill / Drain Plug:
14 ft-lbs (19 Nm)
41. Install the bellcrank onto the shift shaft. Note the key
splined on the bellcrank and shift shaft. Install the nut
and torque to specification.
TORQUE
Bell Crank Nut:
15 ft-lbs (20 Nm)
42. Refer to “Transmission Installation” to complete the
repair.
