9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
3.101
VALVE COVER INSTALLATION
1. Install spark plugs
q
and torque to specification.
TORQUE
Spark Plugs:
9 ft-lbs (12 Nm)
2. Prepare valve cover sealing surfaces by cleaning
thoroughly to remove all residue.
3. Inspect the valve cover seal
w
and replace if
necessary.
4. Replace the isolators
e
around each T40 bolt.
5. Install the four valve cover shoulder bolts
r
and
isolators using a T40 driver.
6. Torque valve cover bolts in sequence to specification.
TORQUE
Valve Cover Bolts:
7 ft-lbs (10 Nm)
ENGINE / COOLING SYSTEM
