9.6
9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
STEERING WHEEL REMOVAL
1. Remove the steering wheel cover
q
.
2. Remove steering wheel retaining nut
w
and remove
steering wheel from the upper steering shaft.
POWER STEERING UNIT REMOVAL
1. Remove the upper steering shaft, pivot tube and
steering wheel from the vehicle as an assembly.
Refer to Upper Steering Shaft Removal page 9.5.
CAUTION
Striking the steering wheel or steering shaft while
installed in the vehicle can permanently damage the
EPS unit and cause a Power Steering Fault.
2. Disconnect the two electrical harnesses
q
from the
power steering unit .
3. Remove the pinch bolt
w
retaining the lower steering
shaft to the power steering unit .
STEERING / SUSPENSION
