9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
1.55
SPN COMPONENT
FMI CONDITION CODE
4 Voltage Below Normal, Or Shorted To Low Source C1021
6 Current Above Normal Or Grounded Circuit C101E
7 Mechanical System Not Responding Or Out Of Adjustment C0020
8 Abnormal Frequency Or Pulse Width Or Period C101F
12 Bad Intelligent Device Or Component C101C
520262
ABS/Brake Controller Source
Voltage
0 Data Valid But Above Normal Operational Range - Most Severe Level C2422
1 Data Valid But Below Normal Operational Range - Most Severe Level C2421
3 Voltage Above Normal, Or Shorted To High Source C1039 / C1241
4 Voltage Below Normal, Or Shorted To Low Source C1038
520264 ABS/Brake Controller ECU
12 Bad Intelligent Device Or Component C1041
12 Bad Intelligent Device Or Component C1243
13 Out Of Calibration C1141
520265 ABS Module
7 Mechanical System Not Responding Or Out Of Adjustment C1042
520266
ABS Brake Switch (Front/Rear)
3 Voltage Above Normal, Or Shorted To High Source C1044
5 Current Below Normal Or Open Circuit C1043
520272
Glow Plug Relay Driver Circuit
3 Voltage Above Normal, Or Shorted To High Source P1384
4 Voltage Below Normal, Or Shorted To Low Source P1383
5 Current Below Normal Or Open Circuit P1385
520273
Fuel Pull Solenoid Relay Driver
Circuit (Low Side)
3 Voltage Above Normal, Or Shorted To High Source P125D
4 Voltage Below Normal, Or Shorted To Low Source P125C
5 Current Below Normal Or Open Circuit P125A
520275
Accelerator Position/Brake Position
Interaction
31 Condition Exists P150A / U1007
520276
Throttle Position Sensor (1 or 2
Indeterminable)
2 Data Erratic, Intermittent Or Incorrect P150C
12 Bad Intelligent Device Or Component P150B
520277
Throttle Body Control - Power
Stage
2 Data Erratic, Intermittent Or Incorrect P151A
3 Voltage Above Normal, Or Shorted To High Source P150D
4 Voltage Below Normal, Or Shorted To Low Source P150E
8 Abnormal Frequency Or Pulse Width Or Period P151B
31 Condition Exists P153F
520278
Throttle Body Control - Return
Spring Check Failed
31 Condition Exists P151C
520279
Throttle Body Control - Adaption
Aborted
31 Condition Exists P151D
520280
Throttle Body Control - Limp Home
Position Check Failed
31 Condition Exists P151E
520281
Throttle Body Control - Mechanical
Stop Adaptation Failure
31 Condition Exists P152A
520282
Throttle Body Control - Repeated
Adaptation Failed
31 Condition Exists P152B
520283
Throttle Body Control
2 Data Erratic, Intermittent Or Incorrect P152F
3 Voltage Above Normal, Or Shorted To High Source P152C
4 Voltage Below Normal, Or Shorted To Low Source P152D
520284
Throttle Body Control - Position
Deviation Fault
31 Condition Exists P152E
520285
Brake Switch (1 or 2
Indeterminable)
2 Data Erratic, Intermittent Or Incorrect P153E
520286
ECU Monitoring Error
31 Condition Exists P1540
520287
ECU Monitoring Error (Level 3)
31 Condition Exists P1541
520288
ECU Monitoring of Injection Cut Off
(Level 1)
31 Condition Exists P1542
520289
ECU Monitoring of Injection Cut Off
(Level 2)
31 Condition Exists P1543
GENERAL INFORMATION
1
