Polaroid ModelSmart 250S User Manual

26
OTHER LCD FUNCTIONALITY
PREHEAT
The Preheat functionality allows you to warm up the extruder prior to starting the printing process.
This is not an essential part of the process but will allow faster printing because the printer can be
carrying out this process whilst you prepare your Scene and print le.
SETTINGS
Under ‘Settings’ you have two further options (excluding returning to the Main Menu).
‘Home Position’ returns the extruder and the print bed to their default position: the extruder to the
rear right-hand corner of the printer, and the print bed being reset to its lowest position.
‘Other Settings’ provides you with two further options; selecting and changing the language of the
LCD, or displaying current Print Status information as shown on the images below:
If you select ‘Preheat’ the on-screen display
will inform you of the current and optimum
temperatures. When the two temperatures display
the same number then the printer is ready for
printing.
You can turn preheating on or off via the LCD at
any time.
Settings
Home Position
Other Settings
Main Menu
Other Settings
Printer Status
Language
Back
Language
Prev Next
Cancel
English
Italian
French
Dutch
OK
1 2
3 4

Polaroid ModelSmart 250S Specifications

General

Print technology	-
Printing material	Polylactic acid (PLA), Wood fiber
Maximum travel speed	100 mm/sec
Layer thickness (max)	350 mm
Layer thickness (min)	50 mm
Maximum build size (WxDxH)	250 x 150 x 150 mm
Filament thickness supported	1.75 mm
Control type	Wireless
Viewing window	Yes
Print resolution	- DPI
3D scanner	No
Compatible memory cards	SD
AC adapter output voltage	24 V
Cables included	AC, USB

Weight and Dimensions

Depth	150 mm
Width	250 mm
