3) Components
Note: Each component is sold separately or in kits.
3.1 Wall Controller (Touch Screen)
Users can input control commands from the wall
   controllertoturnagroup/zoneonando.Itisused
toinputallprogramparameters.ThecolourLCD
   displaysclock,zonestatus,temperatureandother
statuses.
3.2 Main Control Module and Extension Module
(optional)
Maincontrolmodule(8zoneswithbypassport)and
itsoptionalextensionmodule(extra8zones)control
thepositionofmotorizeddamperofeachzone.
3.3 Motorized Damper (Bright Green)
Motorizeddamperdrivesthebladeofthedamperto
   adjusttheairow.
3.4 Cables
   Cableswithleftlatch(fordata)orcentrallatch(for
   control)plugsconnectthemaincontrolmodule,
   extensionmodule(ifapplicable),touchscreen,and
   motorizeddampertogether.
3.5 Supply Air Sensor (optional)
Supply air sensor measures the temperature of the
supply air for safety purposes.
3.6 Power Supply
24VACtransformersprovidepowertothemaincontrol
   moduleandextensionmodule.
3.7 Rechargeable Battery
Thebackupbatteryisusedtostorethetimeand
settings when there is a power surge.
