39
8.2.1. Input parameters SAT reception
DVB > Input signal
Choose the kind of signal
If DVB-T/T2 or
DVB-C is chosen, go further in
the passage TER. reception
Auto > LO frequency
TP > Transponder frequency
Enter transponder frequency
SR > Symbolrate
AUTO sets the required
frequency automatically.
Can however be set to 09750 ,
10600 or another
OTHER frequency.
Search >
After the button Search has
Enter symbol rate
Tuner Locked
If the tuner finds the transponder,
Tuner Locked is displayed in the upper
field.
been activated, the data is
accepted and the desired
transponder is set.
Receiving Conditions
The quality of the input signal can be
evaluated using the bit error ratio
BER and the signal-to-noise ratio SNR .
