PoolPak HCD 2600 - Poolcompak Outside Air Damper Size; Table 3-6. Poolcompak Outside Air Damper Size

21EGW06-PCPEG-20140813
TM
TM
POOLCOMPAK OUTSIDE AIR DAMPER SIZE
Table 3-6. PoolComPak™ Outside Air Damper Size
Section III: Performance and Sizing
Model#
Outside Air (OA)
Location
Opening
Size
1
(in.)
Damper Code OA CFM Range
2
PoolComPak Vertical AWV/HCDV
V550/800/1200
Top
A, 14 x 10
OA-TR
0-800
Left OA-LT
V1400/1800
Top
A, 14 x 10
OA-TR
0-800
Left OA-LT
Top
B, 14 x 22
OA-TR
800-2000
Left OA-LT
V2600
Top
A, 14 x 10
OA-TR
0-800
Left OA-LT
Top
C, 14 x 30
OA-TR
800-2500
Left OA-LT
V3500/4000
Top
A, 14 x 10
OA-TR
0-800
Left OA-LT
Top
C, 14 x 30
OA-TR
800-2800
Left OA-LT
PoolComPak Horizontal AWH/HCDH
H550/800/1200
Top
A, 12 x 12
OA-TC
0-450
Front OA-FC
Top
B, 12 x 24
OA-TC
450-800
Front OA-FC
H1400/1800
Top
C, 16 x 20
OA-TC
0-1000
Front OA-FC
Top
D, 16 x 40
OA-TC
1000-2000
Front OA-FC
H2600/3500/4000
Top
E, 20 x 20
OA-TC
0-1400
Front OA-FC
Top
F, 20 x 40
OA-TC
1400-2800
Front OA-FC
1
Size may change depending on RA CFM and ESP. See product dwg request/pulley
request from section software for exact damper size.
2
Operating these units at OA quantities different from which the unit was selected will
be detrimental to the unit’s operation.
