Porter Reliant - Front and Rear View

PORTER Reliant
9
The unit is designed for indoor use only.
Do not use in presence of anaesthetic or flammable gas.
To avoid an excessive level of humidity, properly air the room where the unit is installed.
2.7 FRONT AND REAR VIEW
Door
Door handle
Control panel
Distilled water recervoir
filling point
Bacterial filter
Door gasket
Quick connector for distilled
water tank drain
Water inlet filter
Water outflow filter
Chamber water inlet
Temperature sensor
Air line filter
Safety valve connection
Air grid and cooling fan
Safety valve
Power supply switch
Power supply cord
Printer connector
(option)
Main fuses
Quick connector for used water
tank drain
Automatic draining of
used water tank (option):
max flow 20 ml/minute,
water T < 70°C
