31. EMC (ELECTROMAGNETIC COMPATIBILITY)
The PLC-8000(pola) complies whit these standards as tabled below. Follow the guidance on the tables for
use of the device in the electromagnetic environment.
PLC-8000(pola) is suitable for the home healthcare environment.
Requirement
Test
Reference
standards
Application
point
Test level
Conducted Disturbance at The
Main Ports
EN55011:2009+A1:2010,
CISPR11:2009+A1:2010
Mains Group 1, Class A
Radiated Disturbance 10m distance Group 1, Class A
Harmonic Current Emissions EN 61000-3-2:2014
IEC 61000-3-2:2014
AC power source Class A
Voltage Fluctuations and Flicker EN 61000-3-3:2013
IEC 61000-3-3:2013
AC power Pst : 1, Plt : 0.65
Dmax : 4%, Tmax : 0.5s, DCmax 3.3%
Electrostatic Discharge(ESD) EN 61000-4-2:2009
IEC 61000-4-2:2008
Product Enclosure Air-Direct ±2, ±4, ±8, ±15kV
Contact-Direct ±8kV
Radiated RF Electromagnetic
Fields
EN 61000-4-3:2006
+A2:2010
IEC 61000-4-3:2006
+A2:2010
Product Enclosure 3 V/m, 80 % Amplitude Modulation (1 kHz)
9 V/m, Pulse Modulation (217 Hz)
27 V/m, Pulse Modulation (18 Hz)
28 V/m, FM ± 5 kHz Deviation (1 kHz sine)
Pulse Modulation (18 Hz)
Pulse Modulation (217 Hz)
Electrical Fast Transient / Burst
(EFT)
EN 61000-4-4:2012
IEC 61000-4-4:2012
AC main
Signal: Clamp
AC Power Ports ±2kV
Signal: ± 1 kV Peak
Repetition Frequency 100kHz
Surges EN 61000-4-5:2014
IEC 61000-4-5:2014
AC main: Direct Differential mode: ± 0.5 kV, ± 1 kV
Common mode: ± 0.5 kV, ± 1 kV, ± 2 kV
Immunity Conducted
Disturbances
EN 61000-4-6:2014
IEC 61000-4-6:2013
AC main: CDN(M3)
Signal: Clamp
Tested frequency0.15 MHz ~ 80 MHz
3 V (6 V in ISM bands), 80 % Amplitude
Modulation (1 kHz)
Magnetic Field Immunity EN 61000-4-8:2010
IEC 61000-4-8:2009
Enclosure x, y, z Frequency 50/60 Hz
30 A/m
Dips and Interruptions EN 61000-4-11:2004
IEC 61000-4-11:2004
Input AC power port
100 V, 50/60 Hz,
240 V, 50/60 Hz
- 100% voltage reduction; 0.5 Period;
0,45,90,135,180,225,270,315 degrees
- 100% voltage reduction; 1 Period; 0 degrees
- 30% voltage reduction; 25/30 Period ; 0
degrees
- 100% voltage reduction; 250/300 Period; 0
degrees
* The equipment is tested under specified conditions of operation.
