Potter PFC-6200 - I;O Circuit Configuration; I;O Circuits as Inputs; I;O Circuits as Outputs; I;O Maximum Impedance Formula

3-26

I/O Circuit Conguration


Note:only operate as Class B.

Example of I/O Circuit Wiring ExampleFigure 24.
I/O 1 I/O 2
- + - +
5.1k EOL
Potter Part #3005013
Notification
Appliance
5.1k EOL
Potter Part #3005013
Normally Open
Dry Contact
I/O Circuits as Inputs

Input Conguration Characteristics:
y
y
I/O Circuits as Outputs

Output Conguration Characteristics:
y
Reverse polarity upon activation.y
y
y

I/O Maximum Impedance Formula
function of the load

(Alarm Current of Notication Appliances) x (Wire Resistance) < 3 Volts
DWG #602-7A
