Solar Boiler
Number
(part 1)
K8
(1)
K8
(2)
K18
(3)
K18
(4)
K9
(5)
Number
(part 2)
Modulating burn
er
Boiler pump
8 X DHW+B 05
9 X DHW/B 06
10 X DHW 07 X
11 X DHW 08 X
12 X B 09 X
13 X B 10 X
14 X 11 X
15 X 12 X X
17 X DHW/B 13 X
18 X DHW/B 14 X X
19 X X 15 X X
20 X X
22 X DHW+B
23 X X DHW/B
24 X X DHW
25 X X DHW
26 X X B
27 X X B
(1) Storage tank charging pump for bufferstorage tank K8
(2) Solar diverting valve for bufferstorage tank K8
(3) Solar charging pump for swimming pool K18
(4) Solar diverter valve for swimming pool K18
(5) External solar exchanger, Solar pump K9; DHW=DHW storage tank, B=Buffer storage tank
(6) The domestic hot water storage tank is charged using collector pump Q5
Tab.24 Check no. heat source 2 (prog.-no. 6213)
Solid fuel boiler
0 No solid fuel boiler
1 Solid fuel boiler, boiler circuit pump
2 Solid fuel boiler, boiler pump, integration of DHW storage tank
Tab.25 Check no. storage tank (prog.-no. 6215)
Buffer storage tank Domestic water storage tank
0 No buffer storage tank 0 No DHW storage tank
1 Buffer storage tank 1 Immersion heater
2 Buffer storage tank, solar connection 2 Solar connection
4 Buffer storage tank, heat generation shutoff valve 4 Primary pump
5 Buffer storage tank, solar connection, source shut-off
valve
5 Charging pump, solar connection
13 Diverter valve
14 Diverting valve, solar connection
16 Primary controller, without heat exchanger
17 Primary controller, 1 heat exchanger
19 Intermediate circuit, without heat exchanger
20 Intermediate circuit, 1 heat exchanger
22 Primary pump/intermediate circuit, without heat ex
changer
23 Charging pump/intermediate circuit, 1 heat exchanger
25 Diverting valve, intermediate circuit, without heat ex
changer
26 Diverting valve, intermediate circuit, 1 heat exchanger
